Lifetime Support 5 Year Warranty 20 days Free Shipping. Models & Options. The Honeywell 3800g has reached end of life. It has been replaced by the Honeywell Hyperion 1300g. The HHP 3800g barcode scanner delivers world-class performance for a broad range of applications. Read the comprehensive Honeywell 3800g Review by POSGuys.

• Illumination: 630 NM Visible Red LED • Receiving Device: 3648 element linear imager • Reading Distance: From.5 in. (1.3 cm) to 18 in. (46 cm) on medium density barcodes • Reading Width: • 7.5 mil code: 7 in. (18 cm) from the nose, 3.5 in. (8.9 cm) wide • 13 mil code: 12.5 in.

(31.8 cm) from the nose, 8.0 in. (20.3 cm) wide • Resolution: 3 mil. (10 cm) distance • Skew Angle: +65o • Pitch Angle: +65o • Horizontal Velocity: 20 in. (51 cm) per second • Minimum Symbol Contrast: 20% • Scan Rate: Up to 270 scans per second • Decode Rate: 270 decodes per second • Length: 4.4 in. (11.2 cm) • Height: 5.9 in.

(15.0 cm) • Width: 3.1 in. (7.9 cm) • Weight: 5.6 oz.

(158.8 g) • Housing: UL 94V0 grade • Power Requirements: • 3800GX5E: 4.5 – 12Vdc at scanner • 3800GX4E: 4.5 – 5.5Vdc at scanner • Current Draw (Maximum): • Input – 5 V Scanning – 235mA Idle – 86mA • Input – 12 V Scanning – 145mA Idle – 65mA • Noise Rejection: Maximum 100mV peak to peak, 10 to 100 kHz • Operating Temperature: +32o F to +122o F (0o C to +50o C) • Storage Temperature: -40o F to 140o F (-40o C to +60o C) • Humidity: 0 to 95%, non-condensing • Mechanical Shock: Operational after 50 drops from 5 ft. (1.5 m) to concrete • Ambient Illumination: 0 – 70,000 lux • ESD Protection: Functional after 15kV discharge • Vibration: Withstands 5G peak from 22 to 300 Hz • Agency: • International: CB scheme to IEC60950-1 & IEC60825-1 Class 1 LED.

• USA: FCC Part 15 subpart B Class B. UL listed to 60950-1. • Canada: ICES-003 Class B. CUL listed to CSA C22.2 No. • Europe: CE 2004/108/EC EMC Directive to EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3. 2006/95/EC Low Voltage Directive.

• GS Mark: GS marked for I.T.E. • Mexico: NOM-NYCE. • Korea: MIC Class A. • Taiwan: BSMI. • Australia/NZ: C-Tick mark. • MTBF: per MIL-HDBK-217F Ground Benign exceeds 100,000 hours • Symbologies: Codabar, Code 3 of 9 including PARAF, Interleaved 2 of 5, Straight 2 of 5 Industrial, Matrix 2 of 5, Code 11, Code 93, Code 128, UPC, EAN/JAN, China Postal Code, GS1 DataBar.

2005 Sunrise/GTIN compliant, and ISBT 128 Concatenation (requires a paid license). • Interfaces: 3800GX5E: All popular PCs and terminals via keyboard wedge, keyboard replacement/direct connect, USB, TTL level RS-232, IBM, 46XX retail terminals, and Retail USB. 3800GX4E: All popular PCs and terminals via keyboard wedge, keyboard replacement/direct connect, USB, and TTL level RS-232 • Warranty: Five-year factory warranty.

Settlers 3 gold edition spolszczenie download. HONEYWELL SCANNING and MOBILITY Products from Intermec, HHP, Datamax, Metrologic, Welch Allyn Formed through the acquisition of Handheld Products (HHP) and Metrologic, Honeywell Scanning and Mobility is the leader in Imaging barcode scanning. Now on its sixth generation of technology, today’s scanners set the standard for performance in reading linear and 2D barcodes.

Products include gun style, hands-free, cordless and fixed mount modular scanners. All these scanners support a range of interfaces including USB, RS232, and Keyboard Wedge. MOBILE TERMINALS Permeating all industries, Dolphin Terminals continue to be the high performance leader in portable data collection. With embedded imager readers capable of scanning all 1d & 2d codes, they facilitate efficient data collection for Warehousing, Transportation, Healthcare and a myriad of other applications.

Featuring long life full-shift Li-ion batteries they come with a range of connectivity options including LAN, WAN and Bluetooth. Problems with the ifit live module help. Dolphins offer Windows Mobile operating systems and web connectivity to assure ease of application development.
